Sony RB1G - Slide Number 291

To Next Page

To Previous Page

RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

291

Troubleshooting

3-2-4. LED Blinking 4x (LED Voltage Error)

For Ayu2/Ayu2L(IC9000) replacement check related

section

4-times blinking

Check

BACKLIGHT_MON

on the B* Board

B* Board

LED driver

Between 0.49V to 1.32V

Note:

(AYU2/Ayu2L) – IC9000

(Brownie)- IC9001

Note:

G BOARD : ( N/A FOR THIS MODEL)

5-times blinking

Check PANEL_VCC

12.5V at pin 47-51 of

CN8001 on

on the B* Board

G-board

Replace the Harness

Between G-board /

Adapter (BK* only)

and

Panel

Replace

the LVDS Harness

Panel (T-con)

change

B* Board

Harness

LVDS Harness

Panel (T-con)

About 12.5V

Symptom

improvement

Symptom

improvement

Symptom

improvement

Confirm Tcon 12V.

3-2-5-1. LED Blinking 5x (T-Con Error) (HG and TE Model)

Size B* Board Type

(Segment: LW)

OTHERS EUROPE JP

24” BLX BLE BLJ

32” BKX/BLX BKE/BLE BKJ/BLJ

42” BKX/BLX BKE/BLE BKJ/BLJ

50” BLX BLE -
