Sony RB1G - Slide Number 77

RB1G CHASSIS
W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/
W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A
77
Troubleshooting
3-3-3. Main Board Power Off Checking (for Main SP Lch & Rch)
No Checking Item OK NG
1 Check fuse F4601 Fuse short Fuse open
2 Check connectivity audio Vcc to GND
C4606 – GND
C4607 – GND
C4608 – GND
C4609 – GND
No short to GND Either 1 short to GND
3 Check connectivity audio +3.3V_MAIN to GND
(only for BKE and BKX board)
IC4601 (Pin8) – GND
IC4601 (Pin27) – GND
No short to GND Either 1 short to GND
4 Check connectivity audio output to GND.
CN4601
Pin 1 – GND
Pin 2 – GND
Pin 3 – GND
Pin 4 – GND
No short to GND Either 1 of pin short to GND
Size B* Board Type
(Segment: LW)
OTHERS EUROPE JP
32” BKX BKE BKJ
42” BKX BKE BKJ
