Sony RB1G - Slide Number 47

To Next Page

To Previous Page

RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

Troubleshooting

3-2-2. LED BLINKING 3x (Audio Error) – BA2 and BM board only (not applicable for this model)

Check 12.5V

( at F4601) to GND

impedance

F4601,IC4601,etc

(B* Board)

Replace F4601

High

enough

Low impedance

IC4601

burn or broken ?

Replace IC4601

Yes

Check broken parts

around IC4601

IC4601,etc

(B* Board)

IC4601 or parts around IC4601 NG

Check the IC4601

Out pin 9, 16, 25, 32

Switching 0V to 12V

around 300-400kHz

Yes

Check the CN4601

DC level ~2V (at

JL4621~JL4624)

L4601-L4604

C4611-C4614

Yes

IC4601 NG

Check the IC4601

I2S line pin 5, 6, 7, 8

(at CL4601~CL4604)

IC9000 NG

Check the IC4601

pin 18 (at CL4606)

is HIGH?

Yes

Solder NG

Note:

(AYU2) – IC9000

(Brownie)- IC9001
