RB1G CHASSIS
W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/
W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A
249
MODEL
KDL-24W600A
ALL 32” & 42”
KDL-50W650A
KDL-24W605A
-L MODELS
KDL-50W655A
KDL-50W656A
KDL-50W657A
KDL-50W670A
KDL-50W680A
KDL-50W685A
REGION
ASIA CHINA AMERICA JAPAN EUROPE
Items added in Supplement-1:
1. Sec 3.
a) Trouble Shooting Flow
b) Trouble Shooting Reference
2. Sec 5.
a) Circuit Board Location (Pg 462)
b) Connector Diagram for KDL-24” (Pg 463 ~ 466)
c) Analog Signal Path (Pg 467 ~ 468)
This shows variant information for the new model (s).
Other information remain the same as original issue.
SUPPLEMENT 1
(Page 247 ~ 461)
