Sony RB1G - HDD-Rec Malfunction; Android Application Malfunction

To Next Page

To Previous Page

RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

215

Troubleshooting

3-11. Wireless Network malfunction (continue)

*1) Come from

the previous page.

Check harness

connection is OK

between HSC and B*

Loose harness

Connect properly

Change

Wi-Fi module

Change B* board

HSC board

Wi-Fi module

If Wi-Fi malfunction happens,

• Wi-Fi module

• HSC board

• Harness between HSC and

B* Board

• B* board are suspected.

Change HSC board

Change harness

Between B* board

and HSC board

Main Harness

Size B* Board Type H*

Board

Type

H**

Board

Type

OTHERS

EUROPE JP

24” BKX BKE BKJ

HIR HSC

32” BKX BKE BKJ

HIR HSC

42” BKX BKE BKJ

HIR HSC
