Sony RB1G - Slide Number 296

To Next Page

To Previous Page

RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

Troubleshooting

5-times blinking

Check PANEL_VCC_SW

12.5V at pin 47-51 of

CN8001 on

on the B* Board

Check Ayu2 board: F9101

Check Ayu2L board: F8001

Replace the Harness

Between G-board /

LW model: N/A

Replace

the LVDS Harness

B* Board

change

B* Board

Harness

LVDS Harness

Panel (T-con)

About 12.5V

Symptom

improvement

Symptom

improvement

Symptom

improvement

Confirm Tcon 12V.

3-2-5-2. LED Blinking 5x (T-Con Error)

Note:

G BOARD : ( N/A FOR THIS MODEL)

Size B* Board Type

(Segment: LW)

OTHERS EUROPE JP

24” BLX BLE BLJ

32” BKX/BLX BKE/BLE BKJ/BLJ

42” BKX/BLX BKE/BLE BKJ/BLJ

50” BLX BLE -

296
