RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

227

Service Adjustment

1. Go to TV standby condition by remote

commander.

2. Press “i+ (info)”, “5”, “Volume-” then “TV power”

on remote.

3. You can see Self Diagnosis Display.

4. To Exit , Press Power Off and On.

4-16. How to Enter Self Diagnosis Display

Remote Commander

SELF CHECK

002 MAIN_POWE ------------ ------------ ------------ 00 Model Name : KDL-46W90AA

003 AFE_I2C ------------ ------------ ------------ 00 Serial Number : --------

003 DC_ALERT ------------ ------------ ------------ 00 Package Number : PKG1.301JPA

003 AUD_PROT ------------ ------------ ------------ 00 Wired MAC : 30:F9:ED:04:2C:17

003 HDMI_EQ ------------ ------------ ------------ 00 Wireless MAC : F0:F0:02:AA:82:DA

003 TU_DEMOD ------------ ------------ ------------ 00 USB dongle : N/A

003 AFE_SPI ------------ ------------ ------------ 00

004 VLED ------------ ------------ ------------ 00 <MAIN> <EXT>

004 LD_ERR ------------ ------------ ------------ 00 DM1.301JPA WF:2.0.0.99

005 TCON_ERR 120823132523 ------------ ------------ 01 WF1.003W00AA WF:0B

005 P_ID_ERR ------------ ------------ ------------ 00 DF1.001W00AA FD:-.---

006 BACKLITE ------------ ------------ ------------ 00 YM1.010W00AA BT:1.2.14.848

007 TEMP_ERR ------------ ------------ ------------ 00 M4.992C

007 FAN_ERR ------------ ------------ ------------ 00 DM1.301W00AA

008 VPC_WDT ------------ ------------ ------------ 00 DD1.016W00AA

008 MEPS_WDT ------------ ------------ ------------ 00 PK1.016W00AA

008 HOST_WDT ------------ ------------ ------------ 00 AM01.300JP

008 STBY_WDT ------------ ------------ ------------ 00

008 AFE_WDT ------------ ------------ ------------ 00 MID:1C117081

010 EMIT_ERR ------------ ------------ ------------ 00 PID:04020000

PNL:LC470EUF-FFP1

00081-000671-00088 0000000000000570-0000000000000132

Diagnosis Display

“VPC”

000 DATA_COPY …WB Data Restore Function (Tcon board-to-B board).

000 BU_TRANS

001 DATA_BACKUP ...WB Data Backup Function (B board-to-Tcon board).

000 BU_FLASH

002 VCOM …VCOM Adjustment Function.

000 ENABLE

001 ADJUST

003 WB …W/B adjustment

004 TEST_PTN

005 PANEL

4-15-3. Tree 3
