RB1G CHASSIS
W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/
W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A
9
Safety Notes
1. Remove 3 connectors
1-8-2 . Method to disassemble Chassis Box (Standing)
2. Remove 5 screws from Chassis Box.
CAUTION
3. Pull opening of Bracket Top area to make gap from
Chassis Box top edge.
Then insert fingers to top edge gap and pull Chassis
Box to release hooks, one side（1 or 2）at one time
4. Take out Chassis Box
42”
Make sure 42" got 8 hooks
32”
Make sure 32" got 6 hooks
Pull
Pull
2
1
