Hookups and Settings
Hooking Up the Recorder
Follow steps 1 to 7 to hook up and adjust the
settings of the recorder.
b Notes
• Plug cords securely to prevent unwanted noise.
• Refer to the instructions supplied with the components
to be connected.
• You cannot connect this recorder to a TV that does not
have a video input jack.
• Be sure to disconnect the power cord of each
component before connecting.
Step 1: Unpacking
Check that you have the following items:
• Audio/video cord (phono plug × 3 y phono
plug × 3) (1)
• Power cord (1)
• Antenna cable (1)
• Remote commander (remote) (1)
• Size AA (R6) batteries (2)
• Plug adapter (1)
Step 2: Connecting the
Antenna Cable
Select one of the following antenna hookups. Do
not connect the power cord until you reach
“Step 5: Connecting the AC power cord” on
page 21.
Note to CATV (cable television) system
installer (in USA)
This reminder is provided to call the CATV (cable
television) system installer’s attention to Article
820- 40 of the NEC (national electrical code) that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.
b Notes
• If your antenna is a flat cable (300-ohm twin lead
cable), use an external antenna connector (not
supplied) to connect the antenna to the recorder.
• If you have separate cables for VHF (very high
frequency) and UHF (ultra high frequency) antennas,
use a UHF/VHF (ultra high frequency/very high
frequency) band mixer (not supplied) to connect the
antenna to the recorder.
If you have Hookup
Cable box or satellite receiver with a
video/audio output
A (page 15)
Cable box with an antenna output
only
B (page 16)
Cable without cable box, or antenna
only (no cable TV)
C (page 17)
