Sony STR-DA2800ES - Page 114

STR-DA2800ES
STR-DA2800ES
114114
ra
IC2501 <zxx (X2)
1 V/DIV, 20 ns/DIV
40 ns
2.6 Vp-p
wa
IC6206 os (X1 (X_OUT))
ya
Q101, 102 (Base)
2 V/DIV, 2 Ps/DIV
4.6 Ps
4.1 Vp-p
uh
IC1410 2 (SW)
10 V/DIV, 1 Ps/DIV
2.6 Ps
21 Vp-p
ys
Q101, 102 (Collector)
20 V/DIV, 2 Ps/DIV
4.6 Ps
41 Vp-p
ua
IC1405 1 (BOOT)
10 V/DIV, 20 ns/DIV
40 ns
23 Vp-p
us
IC1406 1 (BOOT)
10 V/DIV, 20 ns/DIV
40 ns
22 Vp-p
uk
IC3903 qd to qg (PHASE)
2 V/DIV, 5 ns/DIV
10 ns
5.8 Vp-p
ul
IC3904 qd to qg (PHASE)
2 V/DIV, 10 ns/DIV
20 ns
5.8 Vp-p
ug
IC1402 1 (BOOT)
10 V/DIV, 50 ns/DIV
120 ns
22 Vp-p
uf
IC1403 qs (VBST)
2 V/DIV, 500 ns/DIV
1.6 Ps
7.3 Vp-p
uj
IC1408 qs (VBST)
5 V/DIV, 500 ns/DIV
1.6 Ps
14 Vp-p
ud
IC1404 1 (BOOT)
10 V/DIV, 1 Ps/DIV
2.1 Ps
22 Vp-p
1 V/DIV, 100 ns/DIV
250 ns
3.5 Vp-p
5
20.8 Ps
3.4 Vp-p
3
IC1806 qg (DSP LRCK)
1 V/DIV, 10 Ps/DIV
1
IC1806 qd (DSP MCK)
500 mV/DIV, 20 ns/DIV
40 ns
1.9 Vp-p
4
IC1806 e; (XMCK)
1 V/DIV, 20 ns/DIV
40.8 ns
3.9 Vp-p
IC1806 ea (XOUT)
1 V/DIV, 20 ns/DIV
40.8 ns
3.8 Vp-p
2
IC1806 qf (DSP BCK)
1 V/DIV, 200 ns/DIV
326 ns
3.9 Vp-p
20.8 Ps
4.6 Vp-p
qd
IC5001 ol (LRCLK_OUT)
2 V/DIV, 10 Ps/DIV
qa
IC5001 wg (XTAL2)
1 V/DIV, 20 ns/DIV
40 ns
4 Vp-p
qs
IC5001 ok (BCLK_OUT)
2 V/DIV, 200 ns/DIV
326 ns
4.8 Vp-p
ed
IC3700 <zzc (XTALOUT)
1 V/DIV, 20 ns/DIV
36.6 ns
2.1 Vp-p
es
IC3861 wa (XTAL1)
200 mV/DIV, 20 ns/DIV
34.4 ns
600 mVp-p
eg
IC3000 wd (XO)
1 V/DIV, 100 ns/DIV
250 ns
2.5 Vp-p
ef
IC3531 3
500 mV/DIV, 20 ns/DIV
37 ns
1.3 Vp-p
ea
IC3861 2 (HS/CS)
1 V/DIV, 20 Ps/DIV
64 Ps
3.9 Vp-p
ta
IC2501 rd (X1)
1 V/DIV, 100 ns/DIV
250 ns
3.5 Vp-p
• Waveforms
– D-AUDIO Board – – A-VIDEO Board – – DCDC Board –
– NETWORK Board –
– DISPLAY Board –– CONTROL Board –
– DSP Board – – D-VIDEO Board –
