STR-DA2800ES
27
2-19. NETWORK BOARD-2
2
screw
(BVTP3
u
8)
2
screw
(BVTP3
u
8)
2
two screws
(BVTP3
u
8)
1
screw
(P3
u
6)
2
screw
(BVTP3
u
8)
9
two screws
(BVTP3
u
8)
2
screw
(BVTP3
u
8)
4
claw
5
beam-network bracket
0
bracket (NW-R)
6
connector
(CN1103)
7
connector
(CN1104)
3
wiring stopper
8 Remove the NETWORK board block
in the direction of an arrow.
qa NETWORK board
– Rear side view –
Note: When replacing the NETWORK board, refer to “NOTE
OF REPLACING THE NETWORK BOARD” (page 6).
