STR-DA2800ES
30
2-22. A-VIDEO BOARD-2
2-23. CONTROL BOARD
3
screw
(BV S4
u
8)
4
center bracket
6
A-VIDEO board
1 Lean the CONTROL board
in the direction of an arrow.
5
four screws
(BVTP3
u
8)
2
two screws
(BVTP3
u
8)
– Rear side view –
1
connector
(CN2518)
2
connector
(CN2515)
3
connector
(CN2701)
4
Remove the CONTROL board
in the direction of an arrow.
5
CONTROL board
