2-14. D-VIDEO BOARD BLOCK-2
B
A
3
screw
(BVTP3
u
8)
3
screw
(BVTP3
u
8)
3
screw
(BVTP3
u
8)
4
clamp
4
clamp
A
B
6
Push two buttons of connector.
5
Remove the D-VIDEO board block
in the direction of an arrow.
8
D-VIDEO board block
7
flexible flat cable (FFC3)
(CN3101)
SUB D-VIDEO board
(CN7001)
short side
long side
D-VIDEO board
(CN3101)
Note:
When installing the flexible flat cable (FFC3),
check a direction and install correctly.
2
screw
(BVTP3
u
8)
2
screw
(BVTP3
u
8)
1
seven screws
(B3
u
5)
– Rear side view –
