Sony STR-DA2800ES - D-VIDEO Board Section

168
STR-DA2800ES
6-3. D-VIDEO BOARD SECTION
9 101 A-1880-365-A D-VIDEO BOARD, COMPLETE (for SERVICE)
* 102 3-703-150-11 CLAMP
103 3-279-801-31 SHEET, RADIATION
104 3-381-709-21 CUSHION, SARANET
FC1 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
FFC3 1-846-332-11 CABLE, FLEXIBLE FLAT (51 pin)
FFC4 1-828-334-61 WIRE (FLAT TYPE) (13 CORE)
HDC1 1-846-354-11 CABLE, HDMI
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
#5 7-682-546-09 SCREW +B 3X5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
#1
#1
#1
#1
#5
#5
FFC3
FC1
HDC1
NETWORK board section
not supplied
not supplied
not supplied
#1
#1
#1
#1
#1
#1
#1
#1
#1
101
102
not supplied
not supplied
FFC4
not supplied
102
103
104
7
7
8
9
9
0
0
qa
qs
qs
qa
8
– Rear side view –
Note: Wires (fl at type) (Ref. No. FFC4) for service is straight.
Please bend it referring go “HOW TO BEND WIRE
(FLAT TYPE)” on page 35 when you install it in the unit.
