STR-DA2800ES
14
2-4. DCDC BOARD-2
5
two screws
(BVTP3
u
8)
1
screw
(BVTP3
u
8)
3
Remove the DCDC board block
in the direction of an arrow.
7
DCDC board
4
connector
(CN1403)
1
screw
(BVTP3
u
8)
2
claw
2
claw
5
two screws
(BVTP3
u
8)
6
bracket (DC-F)
6
bracket (DC-F)
