2-16. SURR SPEAKER BOARD
Note 1:
In reassembling, use new cable tie
to fasten the clamp same as before.
1 Cut the cable tie.
(See Fig. J)
7 Cut the cable tie.
(See Fig. K)
8 connector
(CN393)
0 SURR SPEAKER board
SURR SPEAKER board
4
two screws
(BVTP3
u
8)
2
screw
(BVTP3
u
8)
5
screw
(BV S4
u
8)
2
two screws
(BVTP3
u
8)
3
crossbeam_fan bracket
6
center bracket
9
three screws
(BV/ring)
:LUHsetting
Note 2:
The wire must not touch heat sink.
Note 2:
The wire must not touch heat sink.
MAIN board
MAIN board
cable tie
cable tie
)LJ-! )LJ.!
–5HDUVLGHYLHZ–
