Sony STR-DA2800ES - Main Block-2

STR-DA2800ES
32
2-25. MAIN BLOCK-2
4
two screws
(BVTP3
u
8)
4
two screws
(BVTP3
u
8)
4
two screws
(BVTP3
u
8)
3
two screws
(BV/ring)
5
main block
2
connector
(CN308)
1 Remove wire
from lead pin.
4
four screws
(BVTP3
u
8)
– Rear side view –
lead pin
 Wire setting
MAIN board
ACDC board
Note:
The wire must not touch power transformer.
