STR-DA2800ES
146
Pin No. Pin Name I/O Description
C20, C21 AVDD1 - Power supply terminal (+3.3V)
C22, C23 DAC5, DAC6 O Component video signal output to the video input selector
D1
OSD_IN[16]/
EXT_DIN[0]
I OSD video data or video data input terminal Not used
D2
OSD_IN[17]/
EXT_DIN[1]
I OSD video data or video data input terminal Not used
D3
OSD_IN[18]/
EXT_DIN[2]
I OSD video data or video data input terminal Not used
D4 GND - Ground terminal
D5 DVDD_IO - Power supply terminal (+3.3V)
D6 MCLK I Master clock signal input from the HDMI transceiver
D7 SDA I/O
Two-way I2C serial data with the video system controller, HDMI transceiver and HDMI input
selector
D8 /CS1 I Chip select signal input from the video system controller
D9 GND - Ground terminal
D10 INT1 O Interrupt signal output to the video system controller (for HDMI transmitter)
D11 INT2 O Interrupt signal output to the video system controller (for HDMI receiver)
D12 DVDD_IO - Power supply terminal (+3.3V)
D13 TEST1 - Test terminal
D14, D15 NC - Not used
D16 RX_5V I Power supply (+5V) input terminal
D17, D18 NC - Not used
D19 RTERM - External resistor connection terminal
D20, D21 AVDD2 - Power supply terminal (+3.3V)
D22 DAC1 O Composite video signal output to the video input selector
D23 DAC2 O Analog video signal output terminal Not used
E1
OSD_IN[13]/
VBI_SCK
I OSD video data or serial data transfer clock signal input terminal Not used
E2
OSD_IN[14]/
VBI_MOSI
I OSD video data or serial data input terminal Not used
E3
OSD_IN[15]/
VBI_/CS
I OSD video data or chip select signal input terminal Not used
E4 DVDD_IO - Power supply terminal (+3.3V)
E20 TEST2 - Test terminal
E21 GND - Ground terminal
E22 COMP2 - External capacitor connection terminal
E23 DAC3 O Analog video signal output terminal Not used
F1 to F4
OSD_IN[9] to
OSD_IN[12]
I OSD video signal input terminal Not used
F20 RSET2 - External resistor connection terminal
F21 PVDD3 - Power supply terminal (+1.8V)
F22 GND - Ground terminal
F23 CEC1 O HDMI CEC data output terminal Not used
G1 to G4
OSD_IN[5] to
OSD_IN[8]
I OSD video signal input terminal Not used
G7 to G9 GND - Ground terminal
G10 DVDD - Power supply terminal (+1.8V)
G11, G12 GND - Ground terminal
G13 DVDD - Power supply terminal (+1.8V)
G14 to
G17
GND - Ground terminal
G20, G21 ELPF1, ELPF2 - External loop fi lter connection terminal
G22 GND - Ground terminal
G23 AVDD3 - Power supply terminal (+3.3V)
H1 to H4
OSD_IN[1] to
OSD_IN[4]
I OSD video signal input terminal Not used
H7 to H17 GND - Ground terminal
H20, H21 GND - Ground terminal
H22 TX1_2+ O TMDS data (positive) output to the HDMI OUT A ARC connector
H23 TX1_2– O TMDS data (negative) output to the HDMI OUT A ARC connector
J1 DE I Data enable signal input from the video A/D converter
J2 HS I Horizontal sync signal input from the video A/D converter
