STR-DA2800ES
148
Pin No. Pin Name I/O Description
U7, U8 GND - Ground terminal
U9 DVDD - Power supply terminal (+1.8V)
U10, U11 GND - Ground terminal
U12 DVDD - Power supply terminal (+1.8V)
U13, U14 GND - Ground terminal
U15 DVDD - Power supply terminal (+1.8V)
U16, U17 GND - Ground terminal
U20 R_TX2 - External resistor connection terminal
U21 GND - Ground terminal
U22 TX2_C+ O TMDS clock (positive) signal output to the HDMI OUT B connector
U23 TX2_C– O TMDS clock (negative) signal output to the HDMI OUT B connector
V1 to V4 P[6] to P[9] I Digital video signal input from the video A/D converter
V20 GND - Ground terminal
V21 PVDD4 - Power supply terminal (+1.8V)
V22 HEAC_2+ I HEAC (positive) signal input terminal Not used
V23 HEAC_2– I HEAC (negative) signal input terminal Not used
W1 to W4 P[2] to P[5] I Digital video signal input from the video A/D converter
W20 TEST3 - Test terminal
W21 PVDD6 - Power supply terminal (+1.8V)
W22 AVDD3 - Power supply terminal (+1.8V)
W23 NC - Not used
Y1, Y2 P[0], P[1] I Digital video signal input terminal Not used
Y3 DDR_DQS[2] O Data strobe signal output to the SD-RAM
Y4 GND - Ground terminal
Y5 DDR_DQ[23] I/O Two-way data bus with the SD-RAM
Y6 DVDD_DDR - Power supply terminal (+1.8V)
Y7 DDR_DQS[3] O Data strobe signal output to the SD-RAM
Y8 GND - Ground terminal
Y9 DDR_A[11] O Address signal output to the SD-RAM
Y10 DVDD_DDR - Power supply terminal (+1.8V)
Y11 DDR_A[4] O Address signal output to the SD-RAM
Y12 GND - Ground terminal
Y13 DDR_/CAS O Column address strobe signal output to the SD-RAM
Y14 DVDD_DDR - Power supply terminal (+1.8V)
Y15 DDR_/CK O Clock signal output to the SD-RAM
Y16 GND - Ground terminal
Y17 DDR_DQ[9] I/O Two-way data bus with the SD-RAM
Y18 DVDD_DDR - Power supply terminal (+1.8V)
Y19 DDR_DQ[14] I/O Two-way data bus with the SD-RAM
Y20 GND - Ground terminal
Y21 DDR_DQ[6] I/O Two-way data bus with the SD-RAM
Y22 DVDD_DDR - Power supply terminal (+1.8V)
Y23 GND - Ground terminal
AA1 DDR_DQ[18] I/O Two-way data bus with the SD-RAM
AA2, AA3 GND - Ground terminal
AA4 DDR_/DQS[2] O Data strobe signal output to the SD-RAM
AA5 DDR_DQ[26] I/O Two-way data bus with the SD-RAM
AA6 DVDD_DDR - Power supply terminal (+1.8V)
AA7 DDR_/DQS[3] O Data strobe signal output to the SD-RAM
AA8 DDR_A[13] O Address signal output terminal Not used
AA9 DDR_A[8] O Address signal output to the SD-RAM
AA10 DVDD_DDR - Power supply terminal (+1.8V)
AA11 DDR_A[2] O Address signal output to the SD-RAM
AA12 GND - Ground terminal
AA13 DDR_/CS O Chip select signal output to the SD-RAM
AA14 DVDD_DDR - Power supply terminal (+1.8V)
AA15 DDR_CK O Clock signal output to the SD-RAM
AA16 GND - Ground terminal
AA17 DDR_DQ[18] I/O Two-way data bus with the SD-RAM
