STR-DA2800ES
150
Pin No. Pin Name I/O Description
1 to 6 D14 to D19 I Video data input terminal Not used
7 DE I Data enable signal input terminal Not used
8 VSYNC I Vertical sync signal input terminal Not used
9 HSYNC I Horizontal sync signal input terminal Not used
10 R0XC– I TMDS clock (negative) signal input terminal Not used
11 R0XC+ I TMDS clock (positive) signal input terminal Not used
12 R0X0– I TMDS data (negative) input terminal Not used
13 R0X0+ I TMDS data (positive) input terminal Not used
14 R0X1– I TMDS data (negative)input terminal Not used
15 R0X1+ I TMDS data (positive) input terminal Not used
16 R0X2– I TMDS data (negative) input terminal Not used
17 R0X2+ I TMDS data (positive) input terminal Not used
18 AVDD12 - Power supply terminal (+1.2V)
19 AVDD33 - Power supply terminal (+3.3V)
20 R1XC– I TMDS clock (negative) signal input from the HDMI input selector
21 R1XC+ I TMDS clock (positive) signal input from the HDMI input selector
22 R1X0– I TMDS data (negative) input from the HDMI input selector
23 R1X0+ I TMDS data (positive) input from the HDMI input selector
24 R1X1– I TMDS data (negative) input from the HDMI input selector
25 R1X1+ I TMDS data (positive) input from the HDMI input selector
26 R1X2– I TMDS data (negative) input from the HDMI input selector
27 R1X2+ I TMDS data (positive) input from the HDMI input selector
28 R2XC– I TMDS clock (negative) signal input from the HDMI input selector
29 R2XC+ I TMDS clock (positive) signal input from the HDMI input selector
30 R2X0– I TMDS data (negative) input from the HDMI input selector
31 R2X0+ I TMDS data (positive) input from the HDMI input selector
32 R2X1– I TMDS data (negative) input from the HDMI input selector
33 R2X1+ I TMDS data (positive) input from the HDMI input selector
34 R2X2– I TMDS data (negative) input from the HDMI input selector
35 R2X2+ I TMDS data (positive) input from the HDMI input selector
36 AVDD12 - Power supply terminal (+1.2V)
37 CVCC12 - Power supply terminal (+1.2V)
38 AVDD33 - Power supply terminal (+3.3V)
39 R3XC– I
TMDS clock (negative) signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 (SA-
CD/CD) connector
40 R3XC+ I
TMDS clock (positive) signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 (SA-
CD/CD) connector
41 R3X0– I
TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 (SA-CD/CD)
connector
42 R3X0+ I
TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 (SA-CD/CD)
connector
43 R3X1– I
TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 (SA-CD/CD)
connector
44 R3X1+ I
TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 (SA-CD/CD)
connector
45 R3X2– I
TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 (SA-CD/CD)
connector
46 R3X2+ I
TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 (SA-CD/CD)
connector
47 R4XC– I
TMDS clock (negative) signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 (BD)
connector
48 R4XC+ I
TMDS clock (positive) signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 (BD)
connector
49 R4X0– I
TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 (BD) connec-
tor
50 R4X0+ I
TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 (BD) connec-
tor
51 R4X1– I
TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 (BD) connec-
tor
52 R4X1+ I
TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 (BD) connec-
tor
D-VIDEO BOARD IC3700 SII9575CTUC (HDMI TRANSCEIVER)
