Pin No. Pin Name I/O Description
F16 AVSS12_HDMI_TX - Ground terminal
F17 AVSS33_HDMI_TX - Ground terminal
F18 AVDD33_VDAC_R - Power supply terminal (+3.3V)
F19 AVSS33_VDAC_X - Ground terminal
F21 VDIN34 O
Update signal output to the sub system controller, main system controller, video system con-
troller and video controller
F22 VDIN23 O VBUS power supply on/off control signal output terminal “H”: power on
F24 ETTXER/DDC_SCL O I2C serial data transfer clock signal output terminal Not used
F25 ETRXD0 I Digital audio/video signal input from the ethernet interface
F26 ETCRS/HPG_RX O Hot plug detection signal output terminal Not used
F27 VDINVSYNC O Vertical sync signal output terminal Not used
F28 VDINCLK O Video clock signal output terminal Not used
G1 INB I Main beam (B) input terminal Not used
G2 INA I Main beam (A) input terminal Not used
G3 TRINA I Tracking signal (A) input terminal Not used
G4 AUX1 I Monitoring signal input terminal Not used
G5 VWDC3O O Laser diode control voltage output terminal Not used
G6 AGND12_1A - Ground terminal
G7 AVSS12_REC - Ground terminal
G9 GPIO2 O Relay drive signal (for main power) output terminal “H”: relay on
G11 BCK O Bit clock signal output to the A/D converter (for network audio section)
G14 AVSS12_APLL - Ground terminal
G15 AVDD12_APLL - Power supply terminal (+1.2V)
G16 AVSS12_HDMI_TX - Ground terminal
G17 AVSS33_VDAC_R - Ground terminal
G20 VDIN35/LIN I
Update signal input from the sub system controller, main system controller, video system
controller and video controller
G23 ETTXD0 O Digital data output to the ethernet interface
G24 ETTXCLK O Serial data transfer clock signal output to the ethernet interface
G25 ETRXD3 I Digital audio/video signal input from the ethernet interface
G26 ETRXCLK I Serial data transfer clock signal input from the ethernet interface
G27,
G28
ETRXD1, ETRXD2 I Digital audio/video signal input from the ethernet interface
H1 IND I Main beam (D) input terminal Not used
H2 INC I Main beam (C) input terminal Not used
H3 TRINC I Tracking signal (C) input terminal Not used
H4 TRINB I Tracking signal (B) input terminal Not used
H5 TRIND I Tracking signal (D) input terminal Not used
H6 FVREF O Reference voltage output terminal Not used
H21 DVCC33_IO_STB - Power supply terminal (+3.3V)
H22 AVSS33_LDO - Ground terminal
H23 ETTXD1 O Digital data output to the ethernet interface
H24 GPIO8/5V_RX I Power supply voltage (+5V) input terminal Not used
H25 ETTXEN O Enable signal output to the ethernet interface
H26 ETTXD3 O Digital data output to the ethernet interface
J3 INH O Sub beam (H) input terminal Not used
J4 ING O Sub beam (G) input terminal Not used
J5 AVDD33_1A - Power supply terminal (+3.3V)
J6 AGND33_1A - Ground terminal
J13, J14 DVCC33_IO_5 - Power supply terminal (+3.3V)
J18, J19 DVCC33_IO_3 - Power supply terminal (+3.3V)
J21 DVCC33_IO_STB - Power supply terminal (+3.3V)
J23 ETTXD2 O Digital data output to the ethernet interface
J24 AVDD33_LDO - Power supply terminal (+3.3V)
J25 UARXD I Receive data input terminal
J26 ETMDIO I/O Two-way management data bus with the ethernet interface
J27 ETCOL I Collision detection signal input from the ethernet interface
J28 ETMDC O Management data clock signal output to the ethernet interface
K1 RFIP I BD RF signal (positive) input terminal Not used
K2 RFIN I BD RF signal (negative) input terminal Not used
