Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA2800ES
192
FB3513 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3514 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3602 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3607 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3608 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3614 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3700 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3701 1-216-864-11 SHORT CHIP 0
FB3702 1-400-921-21 FERRITE, EMI (SMD)
FB3703 1-216-864-11 SHORT CHIP 0
FB3705 1-216-864-11 SHORT CHIP 0
FB3706 1-216-864-11 SHORT CHIP 0
FB3707 1-216-864-11 SHORT CHIP 0
FB3709 1-216-864-11 SHORT CHIP 0
FB3710 1-216-864-11 SHORT CHIP 0
FB3711 1-216-864-11 SHORT CHIP 0
FB3712 1-216-864-11 SHORT CHIP 0
FB3713 1-414-772-11 FERRITE, EMI (SMD) (2012)
FB3714 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3715 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3716 1-469-324-21 FERRITE, EMI (SMD) (2012)
< IC >
IC3000 A-1880-176-A IC MB91F627PMC-G-JNE1 (for SERVICE)
IC3002 6-719-123-01 IC PCA9517DGKR
IC3201 6-707-870-01 IC TC74VHC157FT (EKJ)
IC3500 (Not supplied) IC ADV8003KBCZ-8
IC3503 6-717-680-01 IC BD00IC0WEFJ-E2
IC3504 6-718-379-01 IC RP108J081D-FE
@ IC3505 6-716-700-01 IC K4T1G164QF-BCE7
@ IC3506 6-716-700-01 IC K4T1G164QF-BCE7
IC3507 6-717-680-01 IC BD00IC0WEFJ-E2
IC3508 6-718-999-01 IC MM1839A50NRE
IC3509 6-718-999-01 IC MM1839A50NRE
IC3524 6-707-879-01 IC TC74VHC541FT (EKJ)
IC3531 6-709-888-01 IC TC7WHU04FK
IC3608 6-719-519-01 IC MM1839A18NRE
IC3614 6-715-874-01 IC MM3464A33NRE
IC3615 6-719-061-01 IC MM1839A33NRE
IC3616 6-719-061-01 IC MM1839A33NRE
IC3617 6-719-061-01 IC MM1839A33NRE
IC3700 (Not supplied) IC SII9575CTUC
IC3701 6-718-999-01 IC MM1839A50NRE
IC3703 6-717-680-01 IC BD00IC0WEFJ-E2
IC3704 6-717-680-01 IC BD00IC0WEFJ-E2
IC3705 6-718-379-01 IC RP108J081D-FE
IC3707 6-718-999-01 IC MM1839A50NRE
IC3708 6-718-847-01 IC TMDS442PNPR
IC3860 6-719-061-01 IC MM1839A33NRE
IC3861 6-718-834-01 IC ADV7181CBSTZ
< COIL >
L3501 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
L3502 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
L3503 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
L3504 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
L3505 1-469-525-91 INDUCTOR 10uH
L3613 1-412-977-41 INDUCTOR 0.68uH
L3614 1-412-977-41 INDUCTOR 0.68uH
L3615 1-412-977-41 INDUCTOR 0.68uH
L3616 1-412-977-41 INDUCTOR 0.68uH
L3705 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
L3706 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
< TRANSISTOR >
Q3501 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
Q3502 6-552-930-01 TRANSISTOR LTA043EUBFS8TL
Q3503 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
Q3504 6-552-930-01 TRANSISTOR LTA043EUBFS8TL
< RESISTOR >
R3029 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3030 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3082 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3083 1-218-945-11 METAL CHIP 220 5% 1/16W
R3084 1-218-970-11 METAL CHIP 27K 5% 1/16W
R3085 1-218-945-11 METAL CHIP 220 5% 1/16W
R3206 1-218-949-11 METAL CHIP 470 5% 1/16W
R3301 1-216-864-11 SHORT CHIP 0
R3302 1-218-937-11 METAL CHIP 47 5% 1/16W
R3303 1-216-864-11 SHORT CHIP 0
R3304 1-216-864-11 SHORT CHIP 0
R3305 1-218-929-11 METAL CHIP 10 5% 1/16W
R3306 1-218-929-11 METAL CHIP 10 5% 1/16W
R3307 1-218-929-11 METAL CHIP 10 5% 1/16W
R3308 1-218-937-11 METAL CHIP 47 5% 1/16W
R3309 1-216-864-11 SHORT CHIP 0
R3310 1-216-864-11 SHORT CHIP 0
R3311 1-216-864-11 SHORT CHIP 0
R3312 1-216-864-11 SHORT CHIP 0
R3313 1-216-864-11 SHORT CHIP 0
R3314 1-216-864-11 SHORT CHIP 0
R3315 1-216-864-11 SHORT CHIP 0
R3316 1-216-864-11 SHORT CHIP 0
R3317 1-216-864-11 SHORT CHIP 0
R3318 1-216-864-11 SHORT CHIP 0
R3319 1-216-864-11 SHORT CHIP 0
R3320 1-216-864-11 SHORT CHIP 0
R3324 1-216-864-11 SHORT CHIP 0
R3325 1-216-864-11 SHORT CHIP 0
R3326 1-216-864-11 SHORT CHIP 0
R3327 1-216-864-11 SHORT CHIP 0
R3328 1-216-864-11 SHORT CHIP 0
R3329 1-216-864-11 SHORT CHIP 0
R3330 1-216-864-11 SHORT CHIP 0
R3331 1-218-937-11 METAL CHIP 47 5% 1/16W
R3334 1-216-864-11 SHORT CHIP 0
R3335 1-216-864-11 SHORT CHIP 0
R3336 1-216-864-11 SHORT CHIP 0
R3337 1-216-864-11 SHORT CHIP 0
R3338 1-216-864-11 SHORT CHIP 0
R3339 1-216-864-11 SHORT CHIP 0
R3340 1-218-990-81 SHORT CHIP 0
R3341 1-218-937-11 METAL CHIP 47 5% 1/16W
R3342 1-218-937-11 METAL CHIP 47 5% 1/16W
R3343 1-218-937-11 METAL CHIP 47 5% 1/16W
R3344 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R3345 1-218-937-11 METAL CHIP 47 5% 1/16W
R3346 1-218-937-11 METAL CHIP 47 5% 1/16W
R3347 1-218-937-11 METAL CHIP 47 5% 1/16W
Note: IC3500 and IC3700 on the D-VIDEO board cannot exchange with single.
When these parts are damaged, exchange the complete mounted board.
@ Replacement of IC3505 and IC3506 on the D-VIDEO
board used in this unit requires a special tool.
D-VIDEO
