Sony STR-DA2800ES - Page 199

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA2800ES
199199
< JACK >
J300 1-774-411-11 JACK, PIN 6P
(VIDEO 1 AUDIO OUT, TV IN, SA-CD/CD IN)
J301 1-774-411-11 JACK, PIN 6P (ZONE 2 VARIABLE AUDIO OUT,
SAT/CATV AUDIO IN, VIDEO 1 AUDIO IN)
J302 1-793-777-12 JACK, PIN 2P (SUBWOOFER OUT)
< JUMPER RESISTOR >
JR301 1-216-864-11 SHORT CHIP 0
JR302 1-216-864-11 SHORT CHIP 0
JR303 1-216-864-11 SHORT CHIP 0
JR304 1-216-864-11 SHORT CHIP 0
JR305 1-216-864-11 SHORT CHIP 0
JR306 1-216-864-11 SHORT CHIP 0
JR307 1-216-864-11 SHORT CHIP 0
JR308 1-216-864-11 SHORT CHIP 0
JR309 1-216-864-11 SHORT CHIP 0
JR310 1-216-296-11 SHORT CHIP 0
JR311 1-216-864-11 SHORT CHIP 0
JR312 1-216-864-11 SHORT CHIP 0
JR313 1-216-296-11 SHORT CHIP 0
JR314 1-216-864-11 SHORT CHIP 0
JR315 1-216-864-11 SHORT CHIP 0
JR316 1-216-864-11 SHORT CHIP 0
< COIL >
L500 1-420-872-52 COIL, AIR-CORE
L501 1-420-872-52 COIL, AIR-CORE
L502 1-420-872-52 COIL, AIR-CORE
L503 1-420-872-52 COIL, AIR-CORE
L504 1-420-872-52 COIL, AIR-CORE
L505 1-420-872-52 COIL, AIR-CORE
L506 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q300 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q301 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q302 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q303 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q304 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q305 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q306 8-729-271-31 TRANSISTOR 2SC2713-G
Q307 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q308 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q309 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q310 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q311 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q312 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q500 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q501 8-729-216-22 TRANSISTOR 2SA1162-G
Q502 6-552-660-01 TRANSISTOR KTD1028
Q503 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q504 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q505 8-729-216-22 TRANSISTOR 2SA1162-G
Q506 6-552-660-01 TRANSISTOR KTD1028
Q507 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q508 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q509 8-729-216-22 TRANSISTOR 2SA1162-G
Q510 6-552-660-01 TRANSISTOR KTD1028
Q511 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q512 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q513 8-729-216-22 TRANSISTOR 2SA1162-G
Q514 6-552-660-01 TRANSISTOR KTD1028
Q515 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q516 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q517 8-729-216-22 TRANSISTOR 2SA1162-G
Q518 6-552-660-01 TRANSISTOR KTD1028
Q519 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q520 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q521 8-729-216-22 TRANSISTOR 2SA1162-G
Q522 6-552-660-01 TRANSISTOR KTD1028
Q523 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q524 6-550-327-01 TRANSISTOR 2SA1514KT146S
Q525 8-729-216-22 TRANSISTOR 2SA1162-G
Q526 6-552-660-01 TRANSISTOR KTD1028
Q527 6-550-327-01 TRANSISTOR 2SA1514KT146S
< RESISTOR >
R300 1-216-081-00 METAL CHIP 22K 5% 1/10W
R301 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R302 1-216-864-11 SHORT CHIP 0
R303 1-216-081-00 METAL CHIP 22K 5% 1/10W
R304 1-216-821-11 METAL CHIP 1K 5% 1/10W
R305 1-216-821-11 METAL CHIP 1K 5% 1/10W
R306 1-216-821-11 METAL CHIP 1K 5% 1/10W
R307 1-216-821-11 METAL CHIP 1K 5% 1/10W
R308 1-216-821-11 METAL CHIP 1K 5% 1/10W
R309 1-216-821-11 METAL CHIP 1K 5% 1/10W
R310 1-216-821-11 METAL CHIP 1K 5% 1/10W
R311 1-216-821-11 METAL CHIP 1K 5% 1/10W
R312 1-216-821-11 METAL CHIP 1K 5% 1/10W
R313 1-216-821-11 METAL CHIP 1K 5% 1/10W
R314 1-216-821-11 METAL CHIP 1K 5% 1/10W
R315 1-216-295-91 SHORT CHIP 0
R316 1-216-821-11 METAL CHIP 1K 5% 1/10W
R317 1-216-295-91 SHORT CHIP 0
R318 1-216-864-11 SHORT CHIP 0
R319 1-216-864-11 SHORT CHIP 0
R320 1-216-813-11 METAL CHIP 220 5% 1/10W
R321 1-216-813-11 METAL CHIP 220 5% 1/10W
R322 1-216-821-11 METAL CHIP 1K 5% 1/10W
R323 1-216-841-11 METAL CHIP 47K 5% 1/10W
R324 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R325 1-249-405-11 CARBON 100 5% 1/4W F
R326 1-216-809-11 METAL CHIP 100 5% 1/10W
R327 1-216-809-11 METAL CHIP 100 5% 1/10W
R328 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R329 1-216-845-11 METAL CHIP 100K 5% 1/10W
R330 1-216-809-11 METAL CHIP 100 5% 1/10W
R331 1-216-845-11 METAL CHIP 100K 5% 1/10W
R332 1-216-809-11 METAL CHIP 100 5% 1/10W
R333 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R334 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R335 1-216-833-11 METAL CHIP 10K 5% 1/10W
R336 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R337 1-249-405-11 CARBON 100 5% 1/4W F
R338 1-216-841-11 METAL CHIP 47K 5% 1/10W
R339 1-216-833-11 METAL CHIP 10K 5% 1/10W
R340 1-216-821-11 METAL CHIP 1K 5% 1/10W
MAIN
