Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA2800ES
204
C2541 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2543 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C2544 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2545 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C2546 1-100-159-91 CERAMIC CHIP 22uF 10% 6.3V
C2547 1-100-159-91 CERAMIC CHIP 22uF 10% 6.3V
C2549 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2550 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2552 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2553 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2554 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C2555 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2556 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C2601 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2602 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2606 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2607 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2608 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2609 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2610 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2611 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2612 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6601 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6602 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6603 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR/JACK >
CN604 1-842-128-11 USB CONNECTOR (UWA-C4Z)
CN605 1-785-728-21 PIN (PC BOARD), CONNECTOR 7P
CN701 1-487-957-11 CONNECTOR, HDMI
CN1001 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN1002 1-816-296-21 PIN, CONNECTOR (PC BOARD) 9P
CN1101 1-779-336-51 CONNECTOR, FFC/FPC 24P
CN1102 1-778-383-51 CONNECTOR, FFC/FPC 6P
CN1103 1-779-822-11 CONNECTOR, BOARD TO BOARD 26P
CN1104 1-779-822-11 CONNECTOR, BOARD TO BOARD 26P
CN1106 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
CN2502 1-843-073-11 MODULAR JACK (
1/2/3/4)
CN2601 1-764-177-11 PIN, CONNECTOR (SMD) (1.5 mm) 7P
CN2602 1-691-550-11 PIN, CONNECTOR (1.5 mm) (SMD) 3P
CN3602 1-766-376-21 PIN, CONNECTOR (1.5 mm) (SMD) 9P
< DIODE >
D304 6-502-248-01 DIODE KDZTR3.9B
D305 6-502-248-01 DIODE KDZTR3.9B
D308 6-502-961-01 DIODE DA2J10100L
D601 6-502-961-01 DIODE DA2J10100L
D602 6-502-961-01 DIODE DA2J10100L
D616 8-719-081-67 DIODE M1FM3
D617 6-502-254-01 DIODE KDZTR6.8B
D921 6-502-398-01 DIODE SA10QA04
D1101 6-500-335-01 DIODE MC2838-T112-1
< EARTH TERMINAL >
* ET301 1-780-408-11 TERMINAL, LUG
* ET302 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB901 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB902 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB1101 1-414-594-11 INDUCTOR, FERRITE BEAD
FB1102 1-414-594-11 INDUCTOR, FERRITE BEAD
FB3604 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3605 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3606 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3607 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3608 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3609 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB6601 1-400-794-21 EMI FERRITE (SMD) (1608)
< FILTER >
FL301 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL302 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL303 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL304 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL2501 1-114-724-11 FILTER, EMI REMOVAL (SMD)
FL2502 1-114-724-11 FILTER, EMI REMOVAL (SMD)
FL2503 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 (Not supplied) IC CXD9998G-CB
@ IC106 6-716-964-01 IC K4B2G1646C-HCH9
@ IC107 6-716-964-01 IC K4B2G1646C-HCH9
@ IC206 6-716-964-01 IC K4B2G1646C-HCH9
@ IC207 6-716-964-01 IC K4B2G1646C-HCH9
IC302 6-716-781-01 IC RT8252ALGSP
IC304 6-717-025-01 IC MM3404Z11NRE
IC305 6-705-312-01 IC S-T111B33MC-OGSTFG
IC306 6-702-302-01 IC TK11133CSCL-G
IC307 6-714-911-01 IC TPS54325PWPR
IC308 6-714-911-01 IC TPS54325PWPR
IC309 6-705-312-01 IC S-T111B33MC-OGSTFG
IC312 6-702-302-01 IC TK11133CSCL-G
IC501 (Not supplied) IC H27U4G8F2DTR-BIR
IC601 6-716-739-01 IC BD00GC0WEFJ-SE2
IC602 6-717-441-01 IC BD00GA5WEFJ-E2
IC605 6-716-852-01 IC TPS54425PWPR
IC701 6-702-302-01 IC TK11133CSCL-G
IC702 6-714-926-01 IC MM3404A12NRE
IC901 6-714-846-11 IC WM8524CGEDT/R
IC902 6-712-315-01 IC PCM1807PWR
IC903 8-759-710-97 IC NJM4565M-D
IC907 6-711-214-01 IC TK73350WTL-G
IC908 6-711-237-01 IC NJM2878F3-33 (TE2)
IC1003 6-716-592-01 IC BH76071FJ-E2
IC1099 6-705-313-01 IC S-T111B50MC-OHJTFG
IC1103 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC1105 6-716-768-01 IC DS1339U-33+ T&R
IC1106 6-708-762-01 IC PQ200WNA1ZPH
IC1107 6-717-871-01 IC BDJ0801HFV-TR
IC1108 6-717-873-01 IC BDJ0901HFV-TR
IC2501 6-715-200-01 IC IP175DLF
IC2502 6-716-781-01 IC RT8252ALGSP
IC2503 6-714-424-01 IC MM3404A33NRE
IC2504 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC2601 (Not supplied) IC LM3S615-IQN50-C2T
IC2602 6-711-178-01 IC TC74VHC125FK (EL, K)
IC2603 6-711-178-01 IC TC74VHC125FK (EL, K)
IC6601 6-713-560-01 IC MFI341S2162
@ Replacement of IC106, IC107, IC206 and IC207 on the
NETWORK board used in this unit requires a special tool.
Note: IC101, IC501 and IC2601 on the NETWORK board cannot exchange with
single. When these parts are damaged, exchange the complete mounted board.
NETWORK
