Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA2800ES
209209
R6608 1-218-990-81 SHORT CHIP 0
R6614 1-216-801-11 METAL CHIP 22 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB501 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB502 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB701 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB702 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB801 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB1101 1-234-378-21 RES, NETWORK 10K (1005X4)
RB1102 1-234-378-21 RES, NETWORK 10K (1005X4)
< VIBRATOR >
X401 1-814-278-11 VIBRATOR, CRYSTAL (27 MHz)
* X1102 1-814-303-11 QUARTZ CRYSTAL UNIT (32.768 kHz)
X2501 1-814-242-11 VIBRATOR, CRYSTAL (25 MHz)
X2601 1-795-374-21 VIBRATOR, CERAMIC (6 MHz)
*************************************************************
A-1880-336-A OPT-COAX BOARD, COMPLETE
*************************
< CAPACITOR >
C3604 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3607 1-126-947-11 ELECT 47uF 20% 35V
C3614 1-126-947-11 ELECT 47uF 20% 35V
C3615 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3621 1-126-925-91 ELECT 470uF 20% 10V
C3622 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3731 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3732 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< FERRITE BEAD >
FB3601 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC3603 6-600-827-01 IC JSR1124
(DIGITAL ASSIGNABLE OPTICAL IN 2 (TV))
IC3609 6-709-888-01 IC TC7WHU04FK
IC3625 6-600-827-01 IC JSR1124 (DIGITAL ASSIGNABLE
OPTICAL IN 1 (SAT/CATV))
< JACK >
J3401 1-784-431-11 JACK, PIN 1P
(DIGITAL ASSIGNABLE COAXIAL IN 1 (DVD))
< RESISTOR >
R3605 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R3611 1-216-809-11 METAL CHIP 100 5% 1/10W
R3616 1-218-839-11 METAL CHIP 470 0.5% 1/10W
R3618 1-218-903-11 METAL CHIP 220K 0.5% 1/10W
R3623 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R3778 1-216-809-11 METAL CHIP 100 5% 1/10W
R3813 1-216-864-11 SHORT CHIP 0
R3814 1-216-864-11 SHORT CHIP 0
R3815 1-216-864-11 SHORT CHIP 0
R3816 1-216-864-11 SHORT CHIP 0
*************************************************************
POWERKEY BOARD
****************
< CAPACITOR >
C181 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C182 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< LED >
D181 8-719-057-29 LED SML78423C-TP15 (ON/STANDBY)
< TRANSISTOR >
Q181 6-551-696-01 TRANSISTOR ISA1235AC1-T112-1EF
Q182 6-551-696-01 TRANSISTOR ISA1235AC1-T112-1EF
Q183 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q184 8-729-038-23 TRANSISTOR RT1N141C-TP-1
< RESISTOR >
R182 1-216-864-11 SHORT CHIP 0
R183 1-216-821-11 METAL CHIP 1K 5% 1/10W
R184 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R185 1-216-813-11 METAL CHIP 220 5% 1/10W
R186 1-250-632-11 METAL CHIP 4.7K 1% 1/10W
R187 1-216-813-11 METAL CHIP 220 5% 1/10W
R188 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R189 1-216-821-11 METAL CHIP 1K 5% 1/10W
R190 1-216-809-11 METAL CHIP 100 5% 1/10W
R191 1-250-640-11 METAL CHIP 10K 1% 1/10W
R192 1-216-809-11 METAL CHIP 100 5% 1/10W
R193 1-216-833-11 METAL CHIP 10K 5% 1/10W
R194 1-216-833-11 METAL CHIP 10K 5% 1/10W
< ROTARY ENCODER/SWITCH >
S181 1-418-817-21 ENCODER, ROTARY (INPUT SELECTOR)
S182 1-762-875-21 SWITCH, KEY BOARD (\/1)
S183 1-762-875-21 SWITCH, KEY BOARD (SPEAKERS A/B/A+B/OFF)
S184 1-762-875-21 SWITCH, KEY BOARD (INPUT MODE)
*************************************************************
A-1880-318-A STBY BOARD, COMPLETE
********************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C50 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C52 1-126-963-11 ELECT 4.7uF 20% 50V
C57 1-126-963-11 ELECT 4.7uF 20% 50V
C58 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
0 C958 1-165-530-11 MYLAR 0.47uF 10% 250V
0 C963 1-112-867-51 CERAMIC 220PF 10% 250V
0 C964 1-112-867-51 CERAMIC 220PF 10% 250V
C966 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
0 C967 1-112-869-51 CERAMIC 470PF 10% 250V
0 C968 1-112-869-51 CERAMIC 470PF 10% 250V
< CONNECTOR >
0 CN02 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CN902 1-565-792-11 PIN, CONNECTOR (3.96 mm PITCH) 2P
CN903 1-779-978-11 PIN, CONNECTOR 3P
0 CNP51 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
CNP54 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
NETWORK OPT-COAX POWERKEY STBY
