1-23 (E)
UP-D898MD/X898MD
1. Test Pattern Print
When you select the test pattern and press the menu lever, the printing is started.
The predetermined number of test pattern is printed by setting the number of print in “SV.QTY” in ad-
vance. When you want to discontinue the printing, press the [FEED] button, [OPEN] button, or [CUT]
button on the front portion of this unit.
Menu item Image pattern
C.STP Built-in cross step pattern
N.STP Built-in stair-step pattern
C.LMP Built-in cross lamp image
N.LMP Built-in lamp image
S.LMP Built-in skew lamp image
HD2 Built-in thermal head confirmation pattern 2
HD1 Built-in thermal head confirmation pattern 1
D.ADJ Density adjustment print (not used in service)
00. (L/S)
*
Built-in 100% black pattern
3F. (L/S)
*
Built-in gray pattern (darker)
7F. (L/S)
*
Built-in gray pattern
BF. (L/S)
*
Built-in gray pattern (lighter)
FF. (L/S)
*
Built-in 100% white pattern
* Print size: Horizontal x Vertical [mm]
S: 100 x 75
L: 100 x 117
2. Number of Test Pattern Print
Sets the number of test pattern (PATTERN) print.
SV.QTY:C When setting to continuous print
SV.QTY:10 When setting to 10 sheets.
:
SV.QTY:1 When setting to 1 sheet.
When setting to continuous print, the test pattern is printed continuously.
When you want to discontinue the printing, press the [FEED] button or [OPEN] button on the front
portion of this unit.
3. USB Flash Memory Saving Function ON/OFF
Sets ON/OFF of the function of saving the image data in the USB flash memory.
To enable the change of setting, restart this unit.
The factory setting is “S.MEM:ON”.
. S.MEM:ON: Data can be saved in the USB flash memory.
. S.MEM:OFF: Data cannot be saved in the USB flash memory. This unit does not recognize the USB
flash memory even if it is connected.
