1-25 (E)
UP-D898MD/X898MD
Category Menu Normal Service tool (Printer
Settings)
GET SET
SAVE LOAD RE-
SET
INT
MENU
PWR H.PRN
Normal AUTO.LOCK
OOOO OO
BEEP
OOOO OO
BLANK
OOOO OO
FEED
OOOO OO
PP.TYPE
OOOO OO
SPEED
OOOO OO
Service SV.QTY Initialization and changes are not performed.
OO
STR.MEM
OO
HEAD V
OO
LPF
OO
TMODE
OO
RM.CAP
OO
Printer Infor-
mation
Total Prints(HEAD)
OOO
Power On Time(Power
Unit)
OOO
Others Initialization and changes are not performed.
OO
Error Log All contents Initialization and changes are not performed.
Operation log All contents Initialization and changes are not performed.
8. Mechanical Operation of Individual Motors
Performs the operation of individual motors of this unit.
n
Be sure to use this function after sufficiently understanding the mechanical structure of this unit. Other-
wise, it may cause a breakage.
FEED:FW.H: Performs stepping motor operation. (Paper feed direction, during high speed printing PPS)
FEED:BC.H: Performs stepping motor operation. (Paper return direction, during high speed printing PPS)
FEED:FW.L: Performs stepping motor operation. (Paper feed direction, during low speed printing PPS)
FEED:BC.L: Performs stepping motor operation. (Paper return direction, during low speed printing PPS)
HEAD:OP.F: Performs thermal head operation in the forward direction. (Moves thermal head to OPEN.)
HEAD:HM.F: Performs thermal head operation in the forward direction. (Moves thermal head to HOME.)
HEAD:PR.F: Performs thermal head operation in the forward direction. (Moves thermal head to PRINT.)
HEAD:OP.B: Performs thermal head operation in the backward direction. (Moves thermal head to OPEN.)
HEAD:HM.B: Performs thermal head operation in the backward direction. (Moves thermal head to HOME.)
HEAD:PR.B: Performs thermal head operation in the backward direction. (Moves thermal head to PRINT.)
9. Temperature Display
Displays the current temperature data.
Example)
. H:28.5: Thermal head temperature 28.5 dC
10. Toshiba Mode
Switches whether or not to display the field angles “SC:T1” and “SC:T2” that are exclusive for Toshiba in
the “SCAN” menu. When switched, the content of menu setting is reset.
. TMODE: TM:ON: Enables to select the field angles exclusive for Toshiba
. TM:OFF: Disables to select the field angles exclusive for Toshiba
11. Remote Capture Timing
Adjusts the time from the point the remote key such as remote commander (RM-091) is pressed till the
point the video image is captured.
The video image is captured after waiting for setting value x Vsync minutes.
The factory setting is 0.
To Next Page
