3-21 (E)
UP-D898MD/X898MD
C
A
D
B
Lock arm
FFC guard (HEAD)
MA-195 board
CN701
Flexible flat cable
BVTT
2.6 ) 5
BVTT
2.6 ) 5
PSW3 ) 8
MD top chassis
Head springs
Door block assembly
Heat sink
Thermal head
Cam shaft
The illustration indicates UP-X898MD.
