3-22 (E)
UP-D898MD/X898MD
Installation
10. Write down the head resistance value and serial number of the new thermal head.
11. To install, reverse the removal procedure.
n
When attaching the flexible flat cable and FFC guard (HEAD), route them under the cam shaft.
12. Perform “Procedure after replacement” by referring to Section 3-7-1.
33-XXXXXRXXXXX
Thermal head
Head resistance
value
Serial number
