3-26 (E)
UP-D898MD/X898MD
Tension arm assembly
Pulley of stepping
motor
Timing belt
Helical extension spring
BVTT
2.6 ) 5
BVTT
2.6 ) 5
Motor block assembly
PS3 ) 4
PS3 ) 6
DC motor assembly
CN001
Stepping motor
Harness
