P340 flexiprobe Operation Manual 40
folder – B:/JOBS indicates that you are in the USB flash drive’s JOBS folder.
4. To move from the Compact Flash card to USB flash drive or vice versa just select the drive bar
and press OK or Enter.
5. To enter a folder, select it and press OK or Enter.
6. The screen will now display any sub-folders and files located in the folder you selected.
7. To return to the parent folder select the [..] icon and press OK or Enter.
File types
The P340 card browser will only display compatible files: JPEG, MP4, TXT, XML, BIN, TPG and HTML.
XML files are used to record all your job details and their extension is not shown
BIN, HTML and TPG files are listed only and cannot be viewed on the controller.
Copying files and folders
You can copy or move any file or folder to a different location.
1. Select the file or folder you wish to copy
2. Press COPY or MOVE.
3. Navigate to the folder you want to copy or move the selected item to and press PASTE.
4. Press CANCL if you wish to cancel the operation
NOTE: The controller will automatically provide a default copy name for example Copy_of_05Nov03.
JPEG. Once the file is copied, you can rename it as required.
Renaming files and folders
You can rename any file or folder. The system will add the default extension automatically.
1. Select the file or folder you wish to rename.
2. Press RENAM.
3. Enter a new name and press OK.
CAUTION: Do not rename or move any XML or report file as this will corrupt the HTML report and will
inhibit or corrupt the report conversion by FlexiSight Manager. Do not rename JOBS folders as this will
prevent FlexiSight Manager from importing JOBS and producing reports.
