5 STEVAL-WBC86TX description and operation
5.1 STWBC86 default configuration
Table 4. Basic parameters
Parameter Settings
Transmitter topology A11a
TX bridge mode Full sync
Minimum duty cycle 10 %
Maximum duty cycle 50 %
Minimum operating frequency 120 kHz
Maximum operating frequency 148 kHz
Ping duty cycle 50 %
Ping frequency 146 kHz
Ping duration 80 ms
Ping interval 2,000 ms
Overcurrent protection (OCP) 2 A
Overvoltage protection (OVP) 20 V
Overtemperature protection (OVTP) 100 °C
NTC protection Disabled
Maximum CEP timeout count (for fhop feature) 3
Fhop step 1,920 kHz
Protection debounce 0
FOD debounce 4
• Enabled interrupts
– Bridge mode change
– CEP timeout
– RPP timeout
– Packet sent successfully
– EPT from RX received
– Foreign object detected
– OCP triggered
– OVP triggered
– OVTP triggered
• Enabled features
– Foreign object detection
– Auto ping
– Fhop
– Duty cycle regulation
• EPT conditions after which the device does not start pinging automatically
– Foreign object detected
– OVP triggered
– System error
UM3161
STEVAL-WBC86TX description and operation
UM3161 - Rev 1
page 45/78
