8 Bill of materials
Table 9. STEVAL-WBC86TX bill of materials
Item Q.ty Ref. Value Description Manufacturer Part number
1 4
C6, C8,
CO4, CR4
100nF, C_0402, 50V, 10%,
Min 50V;
X5R/X7R
Wurth 885012205092
2 2 C16, C17 N.M. N.M. N.M.
3 6
CO1, CO2,
CO3, CR1,
CR2, CR3
10uF, C_0805, 35V, 10%,
Min 35V;
X5R/X7R
Murata
GRM21BR6YA106KE43
L
4 6
TP1, TP2,
TP3, TP4,
TP6, TP8
N.M., J_TESTPOINT_1.1mm, PIN N.M. N.M.
5 5
R17, R18,
R23, R24,
R30
5k1, R_0402, 62.5m W, 5%, Resistor Yageo RC0402JR-075K1L
6 4
C12, C21,
C23, C25
100n, C_0402, 50V, 10%,
Min 6.3V;
X5R/X7R
Wurth 885012205092
7 4
CS1, CS2,
CS3, CS4
100nF, C_1206, 50V, 5%, Min 50V; C0G Murata
GRM31C5C1H104JA01
L
8 4
GND,
GND1, VIN,
VINV
HDR1X2, Header 2 Harwin M20-9730245
9 3
R4, R27,
R28
10k, R_0402, 62.5m W, 5%, Resistor Yageo RC0402JR-1310KL
10 7
R6, R7, R8,
R14, R15,
R16, R29
4k7, R_0402, 62.5m W, 5%, Resistor Yageo RC0402JR-134K7L
11 2 C1, C3 10n, C_0402, 50V, 10%,
Min. 50V;
X5R/X7R
Wurth 885012205067
12 2 C9, C10 47pF, C_0402, 50V, 5%,
Min. 6.3V;
X5R/X7R
Wurth 885012005059
13 2 C13, C15 100pF, C_0402, 50V, 10%,
Min. 50V;
X5R/X7R
Wurth 885012205055
14 1 C19 10uF, C_0603, 6.3V, 20%,
Min. 6.3V;
X5R/X7R
Wurth 885012106006
15 4
C7, C20,
C22, C24
4u7, C_0402, 6.3V, 20%,
Min. 6.3V;
X5R/X7R
Wurth 885012105008
16 2 CBT1, CBT2 47nF, C_0402, 50V, 10%,
Min. 50V;
X5R/X7R
Murata
GRT155R71H473KE01
D
17 2 D3, D6 D_0603_LED, 2V, 20mA, RED Wurth 150060RS75000
18 2 D7, D8
D_SMA (DO-214AC), 22V,
400W,
Diode Littelfuse SMAJ22A
19 2
P7, P8
connect coil
760308111
(item 27)
2mm_PIN, COIL N.M. N.M.
20 2 R9, R31 33R, R_0402, 62.5m W, 5%, Resistor Yageo RC0402FR-0733RL
21 2 R10, R13 1k, R_0402, 62.5m W, 5%, Resistor Yageo RC0402JR-071KA
22 2 R11, R19 1M, R_0402, 62.5m W, 5%, Resistor Yageo RC0402JR-7D1ML
23 1 R12 1k, R_0603 Resistor Yageo RC0603JR-071KL
