Item Q.ty Ref. Value Description Manufacturer Part number
24 1 C2 22n, C_0402, 50V, 20%,
Min. 50V;
X5R/X7R
Murata
GCM155R71H223MA55
D
25 1 C4 680p, C_0402, 50V, 10%,
Min. 50V;
X5R/X7R
Wurth 885012205060
26 1 C5 1uF, C_0402, 10V, 20%,
Min. 16V;
X5R/X7R
Wurth 885012105012
27 1
COIL
connect to
P7, P8 (item
19)
Wurth 760308111
28 1 D1 DIOMELF1006N Diode
Diodes
Incorporated
1N4448HLP-7
29 1 D2 N.M., D_SOD882 Diode N.M. N.M.
30 1 D4 D_0603_LED, 2V, 20mA YELLOW Wurth 150060YS55040
31 1 D5 D_0603_LED, 2V, 20mA GREEN Wurth 150060VS55040
32 1 F1
F_SMD_1206_DIN3216M
65V, 3A
Fuse Bourns SF-1206S300W-2
33 1 J1
J_PTH_POWERJACK_2.1M
M, 18V, 1.5A
Barrel connector Kubiconn 163-179PH-EX
34 1 J2
USB_C_UJC-HP-3-SMT-TR,
3A
USB_C_6pin CUI devices UJC-HP-3-SMT-TR
35 1 L1 L_SMD_0805_DIN2012M, 3A Inductor Wurth 742792025
36 1 NTC N.M., HDR1X2 Header 2 N.M. N.M.
37 1 P1 HDR2X3 Header 3X2 Harwin M20-9720345
38 1 P2 HDR2X4 Header 4X2 Harwin M20-9720445
39 1 P3 N.M., 2mm_PIN PIN N.M. N.M.
40 1 J3
J_USB4105-GF-A-120, 20V,
5A
USB Type-C®
connector 16-pin
Wurth 629722000214
41 1
P6 solder
together
P_solderingoption_02
Solder bridge,
keep close
N.M. N.M.
42 1
P10 keep
open
P_solderingoption_02
Solder bridge,
keep open
N.M. N.M.
43 1 P14 HDR1X16 Header 16 Harwin M20-9991645
44 1 R1 5k1, R_0402, 62.5m W, 1% Resistor 1% Yageo RC0402FR-075K1L
45 1 R2 10k, R_0402, 62.5m W, 1% Resistor 1% Yageo RC0402FR-0710KL
46 1 R3 220k, R_0402, 62.5m W, 1% Resistor 1% Yageo RC0402FR-07220KL
47 1 R5 100R, R_0402, 62.5m W, 5% Resistor Yageo AR0402JR-07100RL
48 1 R20 560k, R_0402, 62.5m W, 1% Resistor 1% Yageo RC0402FR-07560KL
49 1 R21 47k, R_0402, 62.5m W, 1% Resistor 1% Yageo RC0402FR-0747KL
50 2 R25, R26 N.M., R_0402, 5% Resistor N.M. N.M.
51 1 S1 SWITCH_P-DT2112C SW-SPST DIPTRONIC P-DT2112C
52 1 TP5 N.M., J_TESTPOINT_1.1mm PIN N.M. N.M.
53 1 TP7 N.M., P_SMD_TEST_12 Test Point N.M. N.M.
54 1 U2 B_72B_240um
STWBC86_Bump
72
STMicroelectronic
s
STWBC86
55 1 U3 U_WQFN28 FT260Q FTDI FT260Q-T
UM3161
Bill of materials
UM3161 - Rev 1
page 60/78
