Item Q.ty Ref. Value Description Manufacturer Part number
56 1 U4 V_SOT23-6L
USBLC6-2SC6,
SOT23-6L
STMicroelectronic
s
USBLC6-2SC6
57 4
Jumpers
short SDA,
SCL, INT,
and POWER
coming from
USB Type-
C® (in the
center of 2x3
header)
Short SDA, SCL,
INT, and POWER
coming from USB
Type-C® (in the
center of 2x3
header)
Wurth 60900213421
58 1
Both sides
tape. Total
length 32m,
means 220
PCBs
(dimension
12.7x13mm)
, 1mm
thickness
3M 5958FR(1/2"X36YD)
59 6
Standoff
Material
requirement
UL94 - V0 or
V1
Standoff, hex
metric, M3
Wurth 970080365
60 4
Untreated
standoff
Material
requirement
UL94 - V0 or
V1
Standoff, M3,
untreated
Wurth 960060042
61 4
Screw with
flat head M3
Material
requirement
UL94 - V0 or
V1
Screw M3 with flat
head
Essentra 50M030050I016
62 2
Screw M3
Material
requirement
UL94 - V0 or
V1
Screw M3 Wurth 97790603111
63 1
Custom
spacer
STEVAL-
WBC86TX
rev A
Material
requirement
UL94 - V0 or
V1
Vendor for plexi Vendor for plexi
