MDG 1
English
25
13 Cover for chainsaws with one-piece
shroud
14 Cover for chainsaws on which
clutch drum or spur sprocket is
exposed after connecting the
engine analyzer.
MDG 1 Engine Analyzer
Power Supply Unit
Electrical appliances must not be
disposed of as household refuse.
Machine, accessories and packaging
must be collected and recycled in an
environmentally beneficial manner.
Specifications
Input voltage: 24 VDC + / - 5%
Input current: max. 1.25 A
Mains voltage: 100 – 240 V
Frequency: 47 – 63 Hz
Output current: max. 1.25 A
Output voltage: 24 VDC + / - 5%
Overvoltage
category: II
Pollution degree: 2
Max. operating
altitude: 2000 m
Max. relative
humidity: 80 %
Max. tolerance of
mains voltage: + / - 10 %
Disposal
