19MS 200, MS 200 T
6. Clutch
– Troubleshooting, b 4.1
– Remove the chain sprocket
cover, bar and chain, b 5
: Pull boot (1) off the spark plug.
: Unscrew the spark plug (1).
: Insert the locking strip (1)
0000 893 5903 – wide end first –
into the cylinder and then turn it
180°.
161RA007 TG
1
161RA008 TG
1
161RA400 TG
1
: Push the locking strip (1)
0000 893 5903 into the spark
plug hole until it butts against the
cylinder wall (arrow) as shown.
: Unscrew the clutch (1).
Note that the clutch has a left-hand
thread.
Disassembling
– Clamp the clutch in a vise.
: Use hook (2) 5910 890 2800 to
remove the clutch springs (1).
161RA401 TG
1
1
161RA010 TG161RA011 TG
2
1
– Pull the clutch shoes off the
carrier.
: Pull the retainers (1) off the clutch
shoes.
– Clean all parts, b 16
– Replace any damaged parts.
: Slip the retainers (1) onto the
clutch shoes.
1
161RA012 TG161RA013 TG
1
161RA014 TG
