10 | Commissioning STOBER
116
05/2019 | ID 442790.01
10 Commissioning
The following sections describe how to commission your drive system using the DriveControlSuite DS6 software.
You can find information about the software's system requirements, installation process and program interface in the
chapter DriveControlSuite [}196].
For the components of your drive model, we require one of the following two combinations:
STOBER synchronous servo motor with EnDat 2.2 digital encoder or HIPERFACE DSL encoder (and optional
brake)
These motors together with all relevant data for the project configuration are saved in the motor database of
DriveControlSuite as well as in the electronic nameplate.
Upon selecting the motor that you want from the database, as well as upon reading out the nameplate, all data is
transferred to the corresponding parameters. There is no need for complex parameterization of the motor, encoder and
brake.
STOBER LM Lean motor without encoder (with optional brake)
These motors are stored in the motor database of the DriveControlSuite, along with all the data relevant for project
configuration. Furthermore, the motor data and the purging and engaging times of the brake are part of the firmware.
By selecting the desired motor from the database, all data is transmitted to the corresponding parameters. The purging and
engaging times of the brake are also stored. If a brake is present, you must only activate this manually. However, complex
parameterization of the motor and brake is not necessary.
All other motor types need to have their parameters configured manually.
Note that the system nodes must be wired and supplied with control voltage before commissioning.
Information
Always perform the steps included in the following chapters in the specified order!
