Stober SC6 Series - Fig. 3 Sticker with MV and Serial Number; Tab. 2 Meaning of the Specifications on the SC6 Nameplate; Tab. 3 Meaning of the Specifications on the Sticker

4 | System configuration STOBER
20
05/2019 | ID 442790.01
Designation Value in example Meaning
Type SC6A062 Production information
ID No. 56690
HW 027 HD
Date 1602
S/N 9001303
Input voltage 3 × 400V
AC
50Hz
UL: 3 × 480V
AC
50 – 60Hz
Input voltage
Input current 10.0A Input current
Output data 0 to 460V
AC
0 to 700Hz
@4kHz: 2 × 4.5A
Output voltage
Output frequency
Output current for 4kHz clock frequency
Protection class IP20 Protection class
Tab. 2: Meaning of the specifications on the SC6 nameplate
Information
UL and cUL-certified devices with corresponding test symbols meet the requirements of the standards UL 61800-5-1 and
CSA C22.2 No. 274.
4.1.1.2 Material variant
On the side of the drive controller next to the nameplate, there is another sticker with the MV and serial number.
Fig.3: Sticker with MV and serial number
Designation Value in example Meaning
MV MV0000012345 MV number
SN 6001192064 Serial number
— SC6A062Z Device type according to type designation
— 1000914812/001100 Order number/order item
Tab. 3: Meaning of the specifications on the sticker
