5 Technical data
Technical data for the drive controllers and accessories can be found in the following chapters.
5.1 Drive controllers
The following chapters contain specifications for the electrical data, dimensions and weight of the drive controller.
5.1.1 General technical data
The following specifications apply to all drive controller types.
Device features
Protection class of the device IP20
Protection class of the installation space At least IP54
Radio interference suppression Integrated line filter in accordance with EN 61800-3:2012, interference
emission class C3
Overvoltage category III in accordance with EN 61800-5-1:2008
Test symbols
Tab. 7: Device features
Transport and storage conditions
Storage/
transport temperature
−20°C to +70°C
Maximum change: 20K/h
Relative humidity Maximum relative humidity 85%, non-condensing
Vibration (transport) in accordance with
DIN EN60068-2-6
5Hz ≤ f ≤ 9Hz: 3.5mm
9Hz ≤ f ≤ 200Hz: 10m/s²
200Hz ≤ f ≤ 500Hz: 15m/s²
Fall height for freefall
1
Weight < 100kg
in accordance with DIN EN61800-2
(or DIN EN 60721-3-2:1997, class2M1)
0.25m
Tab. 8: Transport and storage conditions
Operating conditions
Surrounding temperature during
operation
0°C to 45°C with nominal data
45°C to 55°C with derating −2.5%/K
Relative humidity Maximum relative humidity 85%, non-condensing
Installation altitude 0m to 1000m above sea level without restrictions
1000m to 2000m above sea level with −1.5%/100m derating
Pollution degree Pollution degree 2 in accordance with EN 50178
Ventilation Installed fan
Vibration (operation) in accordance with
DIN EN 60068-2-6
5Hz ≤ f ≤ 9Hz: 0.35mm
9Hz ≤ f ≤ 200Hz: 1m/s²
Tab. 9: Operating conditions
1
Only valid for components in original packaging
