Stober SC6 Series - Power loss data in accordance with EN 61800-9-2

STOBER 5 | Technical data
05/2019 | ID 442790.01
35
5.1.2.8 Power loss data in accordance with EN 61800-9-2
Type Nominal
current
I
2N,PU
Apparent
power
Absolute
losses
P
V,CU
2
Operating points
3
IE class
4
Compariso
n
5
(0/25) (0/50) (0/100) (50/25) (50/50) (50/100) (90/50) (90/100)
Relative losses
[A] [kVA] [W] [%]
SC6A062 4.5 6.2 Max. 10 1.34 1.49 1.86 1.40 1.63 2.19 1.84 2.77 IE2
SC6A162 10 13.9 Max. 10 0.76 0.92 1.43 0.81 1.04 1.75 1.22 2.29 IE2
SC6A261 19 13.2 10 0.77 0.95 1.56 0.82 1.08 1.89 1.25 2.43 IE2
Absolute losses
P
V
[A] [kVA] [W] [W] [%]
SC6A062 4.5 6.2 Max. 10 83.2 92.5 115.2 86.7 100.8 135.8 113.9 171.7 IE2 36.0
SC6A162 10 13.9 Max. 10 105.5 128.3 198.8 113.1 145.1 243.5 170.1 318.7 IE2 40.8
SC6A261 19 13.2 Max. 10 101.2 125.8 206.1 108.5 142.0 249.5 165.6 320.4 IE2 41.0
Tab. 26: Power loss data of the SC6 drive controller in accordance with EN 61800-9-2
General conditions
The specified losses apply to a drive controller. They apply to both axes together in the case of double-axis controllers.
The loss data applies to drive controllers without any accessories.
The power loss calculation is based on a three-phase supply voltage with 400V
AC
/50Hz.
The calculated data includes a supplement of 10% in accordance with EN 61800-9-2.
The power loss specifications refer to a clock frequency of 4kHz.
The absolute losses for a power unit that is switched off refer to the 24 V
DC
power supply of the control electronics.
2
Absolute losses for a power unit that is switched off
3
Operating points for relative motor stator frequency in % and relative torque current in %
4
IE class in accordance with EN 61800-9-2
5
Comparison of the losses for the reference drive controller relative to IE2 in the nominal point (90, 100)
