Stober SC6 Series User Manual

STOBER 15 | Appendix
05/2019 | ID 442790.01
191
15.1.6 GFKIC 2.5 -ST-7.62
Feature Line type Value
Contact spacing — 7.62mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
12A/10A/10A
Max. conductor cross-section Flexible without end sleeve 2.5mm²
Flexible with end sleeve without plastic collar 2.5mm²
Flexible with end sleeve with plastic collar 2.5mm²
2 conductors, flexible, with double end sleeve with
plastic collar
1.0mm²
AWG according to UL/CSA 12
Min. conductor cross-section Flexible without end sleeve 0.2mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve with
plastic collar
0.5mm²
AWG according to UL/CSA 26
Insulation stripping length — 10mm
Tightening torque — —
Tab. 197: Specification for GFKIC 2.5 -ST-7.62
15.1.7 SPC 5 -ST-7,62
Feature Line type Value
Contact spacing — 7.62mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
32A/35A/35A
Max. conductor cross-section Flexible without end sleeve 6.0mm²
Flexible with end sleeve without plastic collar 6.0mm²
Flexible with end sleeve with plastic collar 4.0mm²
2 conductors, flexible, with double end sleeve with
plastic collar
1.5mm²
AWG according to UL/CSA 8
Min. conductor cross-section Flexible without end sleeve 0.2mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve with
plastic collar
0.25mm²
AWG according to UL/CSA 24
Insulation stripping length — 12–15mm
Tightening torque — —
Tab. 198: SPC 5 -ST-7,62 specification
