Symbol Unit Explanation
Ï‘
amb,max
°C Maximum surrounding temperature
T
M
Year, a Length of use
t
min
ms Minimum cycle time of the application
Ï„
th
°C Thermal time constant
U
1
V Input voltage
U
1CU
V Input voltage of the control unit
U
1max
V Maximum input voltage
U
1PU
V Input voltage of the power unit
U
2
V Output voltage
U
2PU
V Output voltage of the power unit
U
max
V Maximum voltage
U
maxMOT
V Maximum motor voltage
U
MOT
V Motor voltage
U
offCH
V Switch-off threshold of the brake chopper
U
onCH
V On limit of the brake chopper
