9 | Connection STOBER
98
05/2019 | ID 442790.01
Top of the device:
ü You have a system circuit diagram describing the connection of the drive controller.
1. Connect the power supply to terminal X10 and attach the terminal.
2. Connect the 24V
DC
power supply for the control electronics to terminal X11 and attach the terminal.
3. If you use the STO safety function, connect it as follows:
3.1. SR6 option: Connect terminal X12 according to your safety configuration.
3.2. SY6 option: In order to be able to identify the safety module in the FSoE network, you must transfer its unique
address in the FSoE network to the drive controller using the DIP switches.
4. Optional: Connect the binary inputs to terminals X101 and X103 and attach the terminals.
5. Connect the fieldbus to the sockets X200 and X201.
You can find examples in the chapter Wiring examples [}193].
