OPERATION
Switching on and off
Switching on:
(1) Switch on the tractor ignition (start engine).
LED L1 lights up.
The controls are in standby mode.
(2) Briefly press the membrane key S1.
LED L1 is flashing.
Depending on the programming, the flashing cycle can look different.
The front loader can now be operated with the joystick.
Switching off:
(1) Briefly press the membrane key S1.
LED L1 lights up.
The controls are in standby mode.
By switching off the ignition, the controls can be completely switched off.
When driving on roads, switch the controls to standby mode to prevent accidental actuation of
the front loader!
Closing and opening the implement locking mechanism
⚠ WARNING
Risk of injury due to implements falling down!
The implement may fall down if the implement locking mechanism is open or not locked correctly. This
can cause serious injury to persons standing in the surrounding area.
Only actuate the implement locking mechanism when the implement is set down on the ground or
on a secure rack.
Always check that the implement is correctly locked.
If the front loader is appropriately equipped, switch S3 can be used to lock and unlock the implement.
Instructions on how to mount and dismount the implement can be found in 6.5 Picking up and
putting down the implement.
Opening the implement locking mechanism:
(1) Press the membrane key S3.
(2) Press the membrane key S3 once more after 2-5 seconds.
LED L3 is flashing.
(3) Pull the joystick to the left (scoop with implement).
The valve switches.
The implement locking mechanism is opened.
Closing the implement locking mechanism:
(1) Press the membrane key S3.
(2) Pull the joystick to the left for at least 3 seconds (scoop with implement).
LED L3 is turned off.
(3) Perform a visual check on the implement locking mechanism.
The implement locking mechanism is closed.
