71 B58FZS 0000000078 EN 002
OPERATION
Working at half-speed
For work that requires particularly careful handling of the load, you can reduce the speed of the front
loader hydraulic system to half.
Switching functions on and off:
(1) Put Pro Control into standby mode (see "Switching on and off").
(2) Press and hold membrane key S2.
(3) Press button T2.
(4) Let go of membrane key S2.
When the half-speed function is switched on, LED L2a flashes in standby mode.
Depressurizing the 3rd control circuit for coupling and uncoupling
⚠ WARNING
Risk of injury due to malfunctions!
This function is only possible with Hydac valves, front loaders with a 3rd control circuit and activated
implement float position. If these conditions are not met, malfunctions can occur and people can be
severely injured.
Ensure that all 3 conditions are met to prevent the occurrence of malfunctions.
Switching functions on and off:
(1) Put Pro Control into standby mode (see "Switching on and off").
(2) Press and hold membrane key S2.
(3) Move the joystick all the way to the left (scooping).
The 3rd control circuit is depressurized.
Depressurizing the 4th control circuit for coupling and uncoupling
⚠ WARNING
Risk of injury due to malfunctions!
This function is only possible with Hydac valves, front loaders with a 3rd and 4th control circuit and
activated implement float position. If these conditions are not met, malfunctions can occur and people
can be severely injured.
Ensure that all 3 conditions are met to prevent the occurrence of malfunctions.
Switching functions on and off:
(1) Put Pro Control into standby mode (see "Switching on and off").
(2) Press and hold membrane key S2.
(3) Move the joystick all the way to the right (dumping).
The 4th control circuit is depressurized.
