Stryker 1069 - Page 90

page 6–51
1069–32–15 Optional Single Articulating Pneumatic Fowler Ass’y
Item Part No. Part Name Qty.
M 1069–32–75 Fowler Skin 1
N25–50 Pop Rivet 9
P7–42 Truss Hd. Screw 4
Q 1069–32–70 Fowler Weldment 1
R 1069–31–12 Barrel Nut 4
S7–62 Truss Hd. Screw 2
T 3001–300–99 Fowler Pivot Bushing 2
U14–87 Nylon Flat Washer 2
V11–180 Steel Flat Washer 2
W16–28 Nylock Nut 4
X13–18 External Tooth Lockwasher 2
Y7–19 Truss Hd. Screw 2
Z38–436 Extension Spring 2
AA 1069–33–110 Head Piece Weldment 1
AB 1069–33–108 Head Pivot Shaft 1
AC 1069–33–107 Hole Plug 2
AD 4–74 Button Hd. Screw 2
AE 4–54 Button Hd. Screw 2
AF 16–11 Nylock Nut 2
AG 15–59 M10 Nut 2
AH 360–31–77 Pneumatic Cylinder 2
AJ 3–37 Hex Hd. Cap Screw 2
AK 4–323 M10 Soc. Hd. Cap Screw 2
AL 1069–31–36 Cylinder Mounting Box 2
AM 16–90 M10 Nylock Nut 2
AN 11–63 Flat Washer 4
AP 52–86 Nyliner 4
AQ 7900–1–102 Velcro Pile 2
AR 1069–60–91 Fowler Release Label, Right 1
AS 1069–60–92 Fowler Release Label, Left 1
AT 11–179 Nylon Washer 4
AU 1069–31–13 Hole Plug 2
AV 966–70–36 Spacer 2
AW 3–20 Hex Hd. Cap Screw 1
AX 966–70–27 Bar Clamp 1
AY 21–73 Set Screw 1
AZ 3–78 Hex Hd. Cap Screw 1
BA 38–171 Compression Spring 1
BB 966–51–19 Modified Wedge Lock 1
BC 11–108 Steel Flat Washer 1
BD 966–51–18 Shaft 1
BE 4–66 Soc. Hd. Cap Screw 1
BF 966–51–24 Knob 1
BG 966–1–65 Label 1
BH 966–70–25 Slide Bar 1
BJ 966–70–37 Spacer 2
BK 14–20 Washer 2
BL 1010–91–57 Weight Label 2
