26 2030-809-002 REV D www.stryker.com
iBED Awareness System Error Codes
Error
Code
Name Description Type Affected Systems
905 CANConnectivity If the footboard does not see the Main board
Heart beat within 10 seconds then the mes-
sage “Communication Failed - Call Service”
Message N/A
906 ScaleFeatures A message will be displayed when user tries
to activate any scale function (Ex. Gain/Loss,
Change Equipment…) that is disabled due
to a logged scale exception (200 Series).
Message “Function Disabled - Call Service”
at 0.8 Hz (70% Duty Cycle) for 4 seconds.
Message N/A
907 ZeroAttemptFailed The “Unable to Zero - Try Again” message
will flash be displayed when the user tries to
zero the bed and the scale system cannot
stabilize the weight in time. Note: This applies
to any use of the zeroing feature, even if that
is within another scale function.
If a zero attempt has failed then the scale
system will be suspended until a successful
zero is saved or the power is cycled. If the
scale button is pressed the “Function Not
Available - Zero Bed” message will flash.
Message N/A
910 LoadCellCheck The load cells will be checked when the
maintenance menu is entered and a message
will be displayed if any load cell errors are
detected. The message should be displayed
“Load Cell Error – HL HR FL FR”. Note: Only
the load cells that are in error will be displayed.
This message will be persistent until any of
the menu type buttons are pressed.
Message N/A
911 MenuException If the footboard menu system is provided with
data that is out of range the display will pres-
ent “Menu Error – Call Service”. The message
will persist until a menu state is correct.
Message N/A
912 CalibrationException If the scale calibration routine fails then the
message “Calibration Error” will be displayed
for 4 seconds and then return to the mainte-
nance menu.
Message Motion
ERROR MESSAGES (CONTINUED)
