Base Assembly and Options
Base Assembly, Standard Components - 3002-200-003 (Reference Only)
Item Part No. Part Name Qty.
B 0003-122-000 Hex Washer Head Screw 8
D 0007-052-000 Truss Head Torx 4
E 0011-310-000 Washer 4
H 0016-002-000 Nylock Nut 8
J 0016-098-000 Hex Flange Nut 8
K 0016-049-000 Nylock Jam Nut 4
L 0018-036-000 Plastic Clip Nut 4
M 0003-224-000 Hex Washer Head Screw 2
N 0026-014-000 Roll Pin 4
P 0038-151-000 Cable Tie 4
R 3002-200-316 Brake Track Roller 1
S 3000-200-305 Brake Shaft Bushing, Right 2
T 3000-200-328 Brake Guide Bushing 4
U 3000-200-331 Brake Shaft Bushing, Left 2
W 3000-200-343 Brake Switch Bracket 1
X 3000-300-002 Plastic Clip Nut 10
Y 3000-300-058 Plunger Switch 1
Z 3000-300-113 8” Cable Tie 6
AA 3000-200-349 Washer 2
AB 3002-301-201 Head End Lift Assembly 1
AC 3002-301-251 Foot End Lift Assembly 1
AD 3001-200-306 Brake Pedal Shaft Bearing 4
AE 3001-200-317 Brake Cam Shaft Bushing 4
AF 3001-200-334 Brake Return Extension Spring 2
AG 3001-200-340 Brake Shaft Assembly, Left 1
AH 3001-200-345 Brake Shaft Assembly, Right 1
AJ 3002-201-301 Brake Ratchet Track 1
AK 3002-200-302 Brake Ratchet Link Assembly 1
AL 3002-200-305 Brake Ratchet Crank, Left 1
AM 3002-200-306 Brake Ratchet Crank, Right 1
AN 3002-200-307 Brake Latch Spring 1
AP 3002-200-308 Brake Ratchet Crank Pin 1
AR 3002-200-311 Brake Shaft 2
AS 3006-200-312 Brake Cam 2
AT 3002-200-313 Brake Cam Spacer 1
AU 3002-200-314 Brake Mounting Bracket 2
AW 3006-200-330 Brake Crank Assembly 2
AX 3006-200-335 Brake Bar Assembly 2
AZ 3000-300-115 Stand-Off 1
GB 0003-074-000 Hex Head Bolt 2
GC 0016-028-000 Nylock Nut 2
GD 3002-316-000 Steer Cable Retaining Clip 2
GF 0011-611-000 Washer 4
GG 0025-191-000 Rivet 4
GH 3006-200-339 Steer/Swivel Lever Bushing 4
GJ 3006-200-374 Swivel Lever 4
GK 3006-200-376 Swivel Lock Activation Spring 4
GL 3006-200-378 Swivel Lock Return Spring, Right 2
GM 3006-200-379 Swivel Lock Return Spring, Left 2
