82 2030-809-002 REV D www.stryker.com
Base Assembly, EPIC II® Bed - 2030-246-003 (Reference Only)
Item Part No. Part Name Qty.
C 0003-333-000 Hex Head Cap Screw 4
X 3000-300-002 Plastic Clip Nut 2
AB 2040-343-200 Zoom Head End Lift Assembly 1
AC 2040-343-250 Zoom Foot End Lift Assembly 1
BB 0023-025-000 Hex Washer Head Screw 12
BC 0023-080-000 Truss Head Phillips Screw 2
BE 0988-002-708 Caution Label 2
BF 3002-300-009 Uni-Pan Cover 2
BG 3000-200-601 Brake Pedal Label 2
BH 3000-200-602 Stryker Logo Label 2
BK 3001-200-022 Bottom Cover Assembly 2
BL 3006-200-105 Offset Base Weldment, Opal 1
GA 2030-001-103 Bellows 2
GE 0059-100-000 Dome Plug 2
6” Caster Option - 3001-999-138 (Reference Only)
Item Part No. Part Name Qty.
FA 3001-200-052 6” Ground Chain 2
FF 2030-200-060 Swivel Lock Caster Assembly, Opal 2
FG 2030-200-065 Steer Swivel Caster Assembly, Opal 2
Base Assembly, Steer Option - 3001-999-137 (Reference Only)
Item Part No. Part Name Qty.
EA 0003-349-000 Hex Head Cap Screw 1
EB 0025-191-000 Rivet 1
ED 0023-092-000 Truss Head Phillips Screw 4
EE 0030-052-000 Heyco Snap Bushing 2
EF 3006-200-380 Steer Extension Spring 1
EG 3006-200-378 Swivel Lock Return Spring, Right 1
EH 0045-008-000 O-Ring 1
EJ 0052-305-000 Flat Washer 1
EK 3000-200-336 Steer Pedal (Rubber) 1
EL 3000-200-337 Push Fit Ball Plunger 1
EM 3006-200-339 Steer/Swivel Lever Bushing 1
EN 3000-200-341 Steer Pedal Bushing 1
EP 0011-611-001 Washer 1
ER 3000-200-348 Washer 1
ES 3000-200-349 Washer 1
ET 3001-200-306 Brake Pedal Shaft Bearing 2
EU 3001-200-342 Steer Cable Assembly 1
EW 3006-200-381 Steer/Swivel Lever 1
EX 3001-200-371 Steer Pedal Arm 1
EY 5000-090-013 Steer Label 1
Base Assembly and Options
